Hyperloop : The Revolutionary Mode Of Transport

Hyperloop

Source:Instagram

A Hyperloop is a proposed mode of passenger and/or freight transportation, first used to describe an open-source vactrain design released by a joint team from Tesla and SpaceX. Drawing heavily from Robert Goddard's vactrain, a hyperloop is a sealed tube or system of tubes through which a pod may travel free of air resistance or friction conveying people or objects at high speed while being very efficient.

Elon Musk's version of the concept, first publicly mentioned in 2012,incorporates reduced-pressure tubes in which pressurized capsules ride on air bearings driven by linear induction motors and axial compressors.

Source:Instagram

The Hyperloop Alpha concept was first published in August 2013, proposing and examining a route running from the Los Angeles region to the San Francisco Bay Area, roughly following the Interstate 5 corridor. The Hyperloop Genesis paper conceived of a hyperloop system that would propel passengers along the 350-mile (560 km) route at a speed of 760 mph (1,200 km/h), allowing for a travel time of 35 minutes, which is considerably faster than current rail or air travel times. Preliminary cost estimates for this LA–SF suggested route were included in the white paper—US$6 billion for a passenger-only version, and US$7.5 billion for a somewhat larger-diameter version transporting passengers and vehicles^[1]—although transportation analysts had doubts that the system could be constructed on that budget; some analysts claimed that the Hyperloop would be several billion dollars overbudget, taking into consideration construction, development, and operation costs.

Source:Instagram

Developments in high-speed rail have historically been impeded by the difficulties in managing friction and air resistance,both of which become substantial when vehicles approach high speeds. The vactrain concept theoretically eliminates these obstacles by employing magnetically levitating trains in evacuated (airless) or partly evacuated tubes, allowing for speeds of thousands of miles per hour. However, the high cost of maglev and the difficulty of maintaining a vacuum over large distances has prevented this type of system from ever being built. The Hyperloop resembles a vactrain system but operates at approximately one millibar (100 Pa) of pressure.

Source:Instagram

Many of the active Hyperloop routes being planned currently are outside of the U.S. Hyperloop One published the world's first detailed business case for a 300-mile (500 km) route between Helsinki and Stockholm, which would tunnel under the Baltic Sea to connect the two capitals in under 30 minutes.Hyperloop One is also well underway on a feasibility study with DP World to move containers from its Port of Jebel Ali in Dubai.Hyperloop One on November 8, 2016, announced a new feasibility study with Dubai's Roads and Transport Authority for passenger and freight routes connecting Dubai with the greater United Arab Emirates. Hyperloop One is also working on passenger routes in Moscow and a cargo Hyperloop to connect Hunchun in north-eastern China to the Port of Zarubino, near Vladivostok and the North Korean border on Russia's Far East.^[ In May 2016, Hyperloop One kicked off their Global Challenge with a call for comprehensive proposals of hyperloop networks around the world.In September 2017, Hyperloop One selected 10 routes from 35 of the strongest proposals: Toronto–Montreal, Cheyenne–Denver–Pueblo, Miami–Orlando, Dallas–Laredo–Houston, Chicago–Columbus–Pittsburgh, Mexico City–Guadalajara, Edinburgh–London, Glasgow–Liverpool, Bengaluru–Chennai, and Mumbai–Chennai.
